Output

Phase

Three-phase+N+PE

Output Voltage

200–1000 VDC

Frequency

50 Hz

Current

Max 300 A

Rated Power

Max 240 kW

Charging Method

Charge simultaneously

Structure

Installation Method

Floor standing

Connector Type

CCS2

Cable Length

5 m (16.40 ft)

Indicator

Yes

HMI

10.1 inch, in color touch screen

Payment Method

RFID/QR code

Meter

MID (PTB customize)

Efficiency

> 95%

Power Factor

> 0.98 (50%–100%)

Harmonic

< 5%

Communication

Charger v.s. Ev

PLC (DIN 70121: 2014-12/ ISO15118)

Communication Protocol

OCPP 1.6J

Environment Indicator

Operating Temperature

–30°C to +50 °C (–22°F to +122°F)

Operating Humidity

5%–95%(RH), non-condensing

Operating Altitude

<2000 m (6561.68 ft)

Enclosure Rating

IP54

Installation Environment

Indoor/Outdoor

Cooling Method

Air-cooling

Noise

≤60 dB

Protection

Multiple Protection

Over voltage/under voltage protection, over load protection, short circuit protection

Certification

CE; IEC 62196; IEC 61851; EMC; EN55011; EN55022; IEC61000-4; IEC 6100-4-5 (6 kV @ 3000A)

Package

Net weight

≤ 500 kg (1102.31 lb)

Gross weight

≤ 550 kg (1212.54 lb)

Package

Wooden case
